| Goff Wire Mesh Belt Specifications |
| Model | WM 24-4-40/60 | WM 27 1/2-4-40/80 | WM 36-8-80/200 | WMV48-8-80/240 |
| Belt Width | 24" | 27-1/2" | 36" | 48" |
| Work Envelope | 24" w x 13 h | 27-1/2" w x 13" h | 36" w x 13" h | 48" w x 13" h |
| Blast Wheels* | (4) 10 HP | (4) 20 HP | (4) 20 HP and
(4) 25 HP |
(8) 30 HP |
| Dimensions | ||||
| Length (A) | 26' | 26' | 26' | 26' |
| Height (B) | 21' | 21' | 21' | 24' |
| Width (C) | 12' | 15' | 13' | 16' |
| Conveyor Work Height (D) | 5'-5 1/4" | 4' | 4' | 5'-11 1/4" |
| Belt Speeds | 3-20 fpm | 3-20 fpm | 3-20 fpm | 3-20 fpm |
| Separator | 14" | 40" | 72" | 140" |
| Dust Collector Requirements | 2500 cfm | 4500 cfm | 5000 cfm | 8200 cfm |
